INDUSTRIAL SLA 3D PRINTER Protofab SLA600A

INDUSTRIAL SLA 3D PRINTER Protofab SLA600A

Regular price Dhs. 166,500.00 AED
Regular price Sale price Dhs. 166,500.00 AED
Sale Sold out

Important:

The price is Ex-works

Stereolithography SLA600A 3D Printer-Compact Master

Top Quality Components

Inside the solid steel frame sits a highly stable granite reinforced printing platform with aerospace grade aluminum Z-axis module, to minimize vibration and maximize precision.

Industrial-grade Building Capacity

Our international best-seller has a maximum build size of 600 x 600 x 400 mm. The SLA600 can satisfy most industrial design and prototyping needs with the lowest per unit cost.

True-to-CAD Accuracy and Surface Finish

Equipped with fast and intuitive printer interface software, and a galvanometer optical system by ScanLab Germany, the SLA600 displays top scanning speeds and enhances production efficiency significantly. Surface roughness as low as 0.05 μm makes post-processing simple and efficient.

Wide Choice of Materials

ProtoFab offers more than 10 self-developed materials, each with their own unique characteristics. Each has been tested extensively and is the perfect match for this equipment.

Made-To-Measure Customization

We offer a considerable selection of customizations free of charge. Available upgrades include autofocus, automatic material refilling, environment sensors, as well as remote diagnostics and control, ensuring you are industry 4.0 ready.

    Specification

    Build Size (xyz)1 600 x 600 x 400 mm (23.62 x 23.62 x 15.75 in)
    Printing Speed 75-180g/h
    Scanning Speed 6.0m/s (Recommended)  10.0m/s (Maximum)
    Accuracy Part Size< 100 mm(3.9 in): ±0.1 mm(±0.004 in)
    Part Size≥ 100 mm(3.9 in):±0.1% x L
    Layer Thickness 0.1 mm (0.004 in)
    Laser Type Diode-pumped solid-state laser Nd:YVO4
    Optical System

    SCANLAB Galvanometer Scanner

    Beam Size: 0.12 - 0.2 mm
    Operating Software Sirius Intelligent Printing Control Software / Linux or Windows (Optional)
    CAD Interface STL Format Files
    Machine Size W x D x H 1630 x 1280 x 1920 mm (64.17 x 50.39 x 75.59 in)
    Ambient Temperature 22-25ºC (71.6-77℉)
    Relative Humidity Less than 40%
    Power Requirements 200-240VAC 50/60Hz Single Phase 16A
