INDUSTRIAL SLA 3D PRINTER Protofab SLA800EX
INDUSTRIAL SLA 3D PRINTER Protofab SLA800EX
Regular price
Dhs. 203,500.00 AED
Regular price
Sale price
Dhs. 203,500.00 AED
Unit price
/
per
Couldn't load pickup availability
Important:
The price is Ex-works
Stereolithography SLA800EX 3D Printer-Compact Master
Miniaturization
The appearance of the equipment is more compact, the floor area is reduced and the transportation cost is reduced. It has comprehensively iterated in optics, electricity, control software and appearance, and the advantages of small batch manufacturing are more prominent. Integrated structure, high stability. The parts are integrated and optimized to improve stability, durability and service life.
Intellectualization
The world's first Linux control system adopts DLC variable laser power control scheme, which has breakthrough productivity. The intelligent variable spot variable power high-speed scanning system improves the printing speed by 20% ~ 100%. The molded parts have extreme details and smooth surface quality.
True-to-CAD Accuracy and Surface Finish
Equipped with fast and intuitive printer interface software, and a galvanometer optical system by ScanLab Germany, the SLA800 displays top scanning speeds and enhances production efficiency significantly. Surface roughness as low as 0.05 μm makes post-processing simple and efficient.
Wide Choice of Materials
A selection of over 10 different custom-designed printing materials with unique characteristics for functional prototypes and low-volume manufacturing.
Specification
Build Size (xyz)1 | 800 x 800 x 550 mm (31.5 x 31.5 x 21.65 in) |
---|---|
Printing Speed | 75-180g/h |
Scanning Speed | 15.2m/s (Maximum) |
Accuracy | Part Size< 100 mm(3.9 in): ±0.15 mm(±0.0059 in) Part Size≥ 100 mm(3.9 in):±0.15% x L |
Layer Thickness | 0.1 mm (0.004 in) |
Laser Type | Diode-pumped solid-state laser Nd:YVO4 |
Optical System |
SCANLAB Germany Galvanometer Scanner Beam Size: 0.12 - 0.2 mm |
Operating Software | Sirius Intelligent Printing Control Software / Linux or Windows (Optional) |
CAD Interface | STL Format Files |
Machine Size W x D x H | 1290 x 1800 x 2350 mm (50.79 x 70.87 x 92.52 in) |
Ambient Temperature | 22-25ºC (71.6-77℉) |
Relative Humidity | Less than 40% |
Power Requirements | 200-240VAC 50/60Hz Single Phase 16A |
