SLA 3D Printing Resin Formula L1-6202 ABS-Like

Formula L1 is an excellent substitute for ABS in 3D printing. Its opaque white color resembles ABS closely, and its physical attributes make it suitable for almost any application. Aside from being strong, it is also highly practical to work with as it only requires the very minimum of post-processing.

Advantages

Highly accurate
Good resistance to humidity
Highly durable
Good resistance to yellowing
Suitable for a very wide range of applications

Applications

Functional prototypes
Concept models
Low-volume production parts

Specifications

Liquid Properties

Measurement	Condition	Value
Viscosity	@ 25.1 °C (77.2 °F)	583 cps
Color		White
Density	@ 25 °C (77 °F)	1.12 g/cm³

Optical Properties

Ec(critical exposure)	Dp(slop of cure-depth vs.ln(E) curve)
9.58mJ/cm2	0.125

Mechanical Properties (90 Minutes UV Postcure)

ASTM Method	Property Description	Value
ASTM D 638	Tensile Modulus	2956 MPa
ASTM D 638	Tensile Strength at Break	55.67 MPa
ASTM D 638	Elongation at Break	8.8%
ASTM D 648 @66PSI	Heat Deflection Temperature	50-55℃
ASTM D 790	Flexural Strength	67.89 Mpa
ASTM D 790	Flexural Modulus	2956 Mpa
ASTM D 256	Izod Impact (Notched)	42.66 J/m
ASTM D 2240	Hardness Shore D	82
