Introduction
The Magna L90 is very similar to the Magna L100 and has excellent overall performance, but the heat resistance is slightly lower than the Magna L100. Magna L90 is ivory color and has a heat resistance of 60 ° C. It has excellent strength and durability as well as excellent surface and dimensional accuracy. It has excellent corrosion resistance to various solvents and oils.
Details
Magna L90 has a heat resistance of 60 ° C, which approximates the performance and appearance of ABS. The excellent temperature resistance makes the Magna L90 suitable for a wider range of applications, including luminaires and automotive interiors. The surface texture is smooth and fine after molding, and requires very little post-processing, which greatly reduces the production period of the hand model.Advantages
High temperature resistance
Excellent detail and surface texture
Easy to make and post-process
Applications
Automobile industry
High temperature model making
Wind tunnel test
Electronics housing
Dental orthodontics
Lighting production
Specification
Liquid Properties
|
Measurement |
Condition |
Value |
|
Viscosity |
@ 25.5 °C (77.9 °F) |
546 cps |
|
Color |
Canary yellow |
|
|
Density |
@ 25 °C (77 °F) |
1.127 g/cm³ |
Optical Properties
|
Ec(critical exposure) |
Dp(slop of cure-depth vs.ln(E) curve) |
|
9.33 mJ/cm2 |
0.13 |
Mechanical Properties (90 Minutes UV Postcure)
|
ASTM Method |
Property Description |
Value |
|
ASTM D 638 |
Tensile Modulus |
1271.3 MPa |
|
ASTM D 638 |
Tensile Strength at Break |
59.75 MPa |
|
ASTM D 638 |
Elongation at Break |
4.7% |
|
ASTM D 648 @66PSI |
Heat Deflection Tempertature |
60 ℃ |
|
ASTM D 790 |
Flexural Strength |
44.71Mpa |
|
ASTM D 790 |
Flexural Modulus |
951.2Mpa |
|
ASTM D 256 |
Izod Impact (Notched) |
38.44 J/m |
|
ASTM D 2240 |
Hardness Shore D |
82 |
